The Diamond Long Wire Saw is an industrial cutting machine designed for high-precision, large-scale stone cutting. Equipped with an extended diamond wire, it is ideal for cutting large blocks of marble, granite, limestone, and construction stone efficiently and accurately. The long wire design allows deep cuts, high cutting speed, and reduced material waste, making it suitable for quarries, workshops, and construction sites.

Diamond Long Wire Saw – Product Specifications

Wire & Cutting System

• Wire Type: High-tensile steel core with industrial diamond beads
• Wire Diameter: 8 mm – 12 mm (thinner for tiles, thicker for granite and large blocks)
• Wire Length: 20 m – 100 m depending on quarry or block size
• Beads per Meter: 28 – 40 beads/m for optimal cutting efficiency
• Cutting Mechanism: Diamond beads grind through stone via a continuous moving wire
• Kerf (Cut Width): Narrow for minimal material loss

 Machine & Drive System

• Power Options: Electric motor (22 kW – 75 kW) or Diesel generator
• Wire Tension Adjustment: Adjustable for different stone hardness
• Cutting Speed (Wire Speed): 15 – 35 m/sec depending on stone type
• Control System: PLC or digital panel with safety stop

 Mobility & Construction

• Frame Material: Heavy-duty welded steel
• Cooling System: Water feed to reduce heat and dust
• Durability: Industrial-grade construction for quarries and workshops
• Applications: Block extraction, slab cutting, tile sizing, and stone shaping

 Material Compatibility

• Marble: Clean, precise cuts with minimal chipping
• Tiles: Fine cuts for construction finishing
• Granite & Limestone: High cutting force for large, hard blocks
• Sandstone & Other Construction Stones: Efficient deep cuts

 Key Benefits

• Deep Cuts: Long wire allows large block cutting
• High Efficiency: Reduces cutting time while maintaining accuracy
• Minimal Waste: Narrow kerf preserves more material
• Versatile Applications: Works in quarry, workshop, and on-site construction
